概要
本サンプルはFortran言語によりLAPACKルーチンZHBEVXを利用するサンプルプログラムです。
エルミート帯行列の半開区間![$ (-2, 2]$](img/img82.gif){kind=small}
の固有値と対応する固有ベクトルを求めます。
入力データ
（本ルーチンの詳細はZHBEVX のマニュアルページを参照）| このデータをダウンロード |
ZHBEVX Example Program Data
5 2 :Values of N and KD
-2.0 2.0 :Values of VL and VU
(1.0, 0.0) (2.0,-1.0) (3.0,-1.0)
(2.0, 0.0) (3.0,-2.0) (4.0,-2.0)
(3.0, 0.0) (4.0,-3.0) (5.0,-3.0)
(4.0, 0.0) (5.0,-4.0)
(5.0, 0.0) :End of matrix A
出力結果
（本ルーチンの詳細はZHBEVX のマニュアルページを参照）| この出力例をダウンロード |
ZHBEVX Example Program Results
Number of eigenvalues found = 2
Eigenvalues
-1.4094 1.4421
Selected eigenvectors
1 2
1 0.6367 0.4516
0.0000 0.0000
2 -0.2578 -0.3029
0.2413 -0.4402
3 -0.3039 0.3160
-0.3481 0.2978
4 0.3450 -0.4088
-0.0832 -0.3213
5 -0.2469 0.0204
0.2634 0.2262
ソースコード
（本ルーチンの詳細はZHBEVX のマニュアルページを参照）※本サンプルソースコードのご利用手順は「サンプルのコンパイル及び実行方法」をご参照下さい。
| このソースコードをダウンロード |
Program zhbevx_example
! ZHBEVX Example Program Text
! Copyright 2017, Numerical Algorithms Group Ltd. http://www.nag.com
! .. Use Statements ..
Use lapack_example_aux, Only: nagf_file_print_matrix_complex_gen
Use lapack_interfaces, Only: zhbevx
Use lapack_precision, Only: dp
! .. Implicit None Statement ..
Implicit None
! .. Parameters ..
Real (Kind=dp), Parameter :: zero = 0.0E+0_dp
Integer, Parameter :: nin = 5, nout = 6
Character (1), Parameter :: uplo = 'U'
! .. Local Scalars ..
Real (Kind=dp) :: abstol, vl, vu
Integer :: i, ifail, il, info, iu, j, kd, ldab, ldq, ldz, m, n
! .. Local Arrays ..
Complex (Kind=dp), Allocatable :: ab(:, :), q(:, :), work(:), z(:, :)
Real (Kind=dp), Allocatable :: rwork(:), w(:)
Integer, Allocatable :: iwork(:), jfail(:)
! .. Intrinsic Procedures ..
Intrinsic :: max, min
! .. Executable Statements ..
Write (nout, *) 'ZHBEVX Example Program Results'
Write (nout, *)
! Skip heading in data file
Read (nin, *)
Read (nin, *) n, kd
ldab = kd + 1
ldq = n
ldz = n
m = n
Allocate (ab(ldab,n), q(ldq,n), work(n), z(ldz,m), rwork(7*n), w(n), &
iwork(5*n), jfail(n))
! Read the lower and upper bounds of the interval to be searched,
! and read the upper or lower triangular part of the matrix A
! from data file
Read (nin, *) vl, vu
If (uplo=='U') Then
Read (nin, *)((ab(kd+1+i-j,j),j=i,min(n,i+kd)), i=1, n)
Else If (uplo=='L') Then
Read (nin, *)((ab(1+i-j,j),j=max(1,i-kd),i), i=1, n)
End If
! Set the absolute error tolerance for eigenvalues. With ABSTOL
! set to zero, the default value is used instead
abstol = zero
! Solve the band symmetric eigenvalue problem
Call zhbevx('Vectors', 'Values in range', uplo, n, kd, ab, ldab, q, ldq, &
vl, vu, il, iu, abstol, m, w, z, ldz, work, rwork, iwork, jfail, info)
If (info>=0) Then
! Print solution
Write (nout, 100) 'Number of eigenvalues found =', m
Write (nout, *)
Write (nout, *) 'Eigenvalues'
Write (nout, 110) w(1:m)
Flush (nout)
! ifail: behaviour on error exit
! =0 for hard exit, =1 for quiet-soft, =-1 for noisy-soft
ifail = 0
Call nagf_file_print_matrix_complex_gen('General', ' ', n, m, z, ldz, &
'Selected eigenvectors', ifail)
If (info>0) Then
Write (nout, 100) 'INFO eigenvectors failed to converge, INFO =', &
info
Write (nout, *) 'Indices of eigenvectors that did not converge'
Write (nout, 120) jfail(1:m)
End If
Else
Write (nout, 100) 'Failure in ZHBEVX. INFO =', info
End If
100 Format (1X, A, I5)
110 Format (3X, (8F8.4))
120 Format (3X, (8I8))
End Program
